Tarter 200 Series Rotary Tiller
If you have gardening or food plot projects, the 200 Series 5ā² Rotary Tiller quickly cultivates, aerates, and stirs up the soil to prep your land properly for seed or planting. Adjustable skid shoes allow for tilling depths up to 7ā³ after multiple passes, and the reversible tine rotation option breaks up the toughest soil. A cast iron top gearbox and formed steel side gearbox house forged and hardened steel gears.
With a heavy-duty slip clutch, thereās less worry about damaging the PTO if the implement jams on a rock or foreign object. If you do though the self-sharpening, heat-treated cutting tines are durable, yet replaceable.
The Tarter 200 Series 5ā² Rotary Tiller is Cat 1 and Quick Hitch compatible, ideally suited to tractors 25-60 PTO HP.
Also available in 6ā and 7ā models.
SPECS
| Ā Tractor PTO Horsepower | 25-50 |
| Hitch Type | Cat 1 |
| Working Width | 58.75 in. |
| Working Depth | 7 in. |
| Driveline | 540 RPM Slip Clutch Protection |
| Number of Flanges on Rotor | 7 |
| Number of Tines per Flange | 6 |
| Rotor Rotation | Reversible (FWD/ REV) |
| Rotor Shaft Speed | 211 rpm @ 540 rpm PTO |
| Skid Shoes | adjustable (0.4 in., 1.4 in.,2.4 in.) |
| Top Gearbox Construction | Cast Iron Housing, Hardened Steel Gears |
| Side Drive Construction | Formed Steel Housing, Hardened Steel Gears |
| Top Gearbox Lubrication | EP 80-90W gear oil |
| Side Drive Lubrication | EP 80-90W gear oil |
| Major Construction | 0.375 in. solid steel gearbox plate and endplates, 0.625 in. steel hitch frame |
| Part | RT205BL |
| Width | 64 in. |
| Approx. Weight | 638 lbs |
| Color | BLACK |
| Quick Hitch Compatible | Yes |
| Warranty | 1 Year |
Ā
Gearbox requires approximately 4 quarts of EP 80-90W gear oil (not included) and must be filled prior to operation.
